Multimash Circular Screen

Multimesh Circular Screen

With the groundbreaking technological application, as one of the leading manufacturers, and suppliers, we offer definite advantages of Plain Dutch weave as well as Twilled Dutch weave for application in BOPP Film Plants, Woven Sacks, PET and non-woven fabric plants. Available in sizes ranging from 12/72, 24/110, 40/200, 50/250, 80/400, 100/600, 165/800, 165/1400, 200/600 and 200/1400 meshes for custom-made screens as per your requirements.

PLAIN-DUTCH WEAVE

The Plain Dutch weave is a type of weave with larger warp wires than the weft wires. The weave is made up of a limited number of warp wires interwoven with the maximum number of weft wires, thereby producing a stable and strong cloth. The warp wires in this weave type are always stronger than the weft wires. The so-called “Zero-Mesh” is created by positioning the weft wires as closely as possible together. This weave type has a high filtration level and high-pressure resistance.

Plain Dutch Weave

TWILLED-DUTCH WEAVE

The Dutch twill weave is similar to the plain Dutch weave, except that the weave has a twill pattern and a double layer of weft threads. In Dutch Twilled Weave each of the warp and Shute wires are woven alternately over two or more successive Shute and warp wires, keeping a constant distance between adjacent susceptive. The mesh has a broad application tendency of supporting larger loads and finer filtrations. We are a leading manufacturer, and supplier of plain dutch weave filter cloth and twilled dutch weave filter cloth from Ahmedabad, India.

Twilled Dutch Weave
  PLAIN AND TWILL DUTCH WEAVE FILTER CLOTH
WARP/SHUTE MESH GAUGE WIRE DIAMETER NOMINAL MICRON RETENTION
12/72 25 x 27 0.50 x 0.41 300
24/110 28 x 32 0.376 x 0.274 80
30/250 38 x 42 0.132 x 0.102 53
40/200 36 x 38.5 0.19 x 0.14 70
50/250 38.5 x 41 0.140 x 0.112 60
50/600 40 x 44 0.122 x 0.081 30
80/400 40 x 45.5 0.102 x 0.063 40
80/700 42 x 44 0.102 x 0.063 35
100/600 42 x 45.5 0.102 x 0.081 25
120/600 42 x 45.5 0.102 x 0.063 28
165/800 45 X 47 0.08 X 0.05 15
170/1400 43.5 x 48 0.063 x 0.040 10
200/600 47 x 48 0.050 x 0.040 20
200/1400 47 x 48 0.050 x 0.040 5
325/2300 48 x 40 0.040 x 0.122 8
